Chevron Drag Bits

Chevron drag bits are designed for use in soft formations such as sand, clay, or some types of soft rock. Draggits can be either solid or welded construction. However, they will not work well in coarse gravel or hard rock formations. Uses include drilling waterwells, mining, geothermal, environmental, and exploration drilling.

Description

AME DRILL Chevron drag bits

Drag bit designed for use in soft formations such as sand, clay, or some types of soft rock. Draggits can be either solid or welded construction. However, they will not work well in coarse gravel or hard rock formations. Uses include drilling waterwells, mining, geothermal, environmental, and exploration drilling.

Chevron drag bits a one-piece constructions of alloy steel cast with tungsten carbide cutting tips and gauge sides to ensure longer life. Chevron-type drag bits are recommended for drilling in slightly harder and more consolidated materials than step-type drag bits, such as hard shales, limestone, and tougher gravels.

Chevron drag bit wings:

Three-wing chevron drag bit, four-wing chevron drag bit;

Drag bits diameter:

76 mm to 445mm;

Drag bits thread sizes:

2 3/8” API Reg, 3 1/2” API Reg, 4 1/2” API Reg, 6 5/8” API Reg, etc.;

Features of Chevron Drag Bits

Chevron Drag Bits are engineered to provide enhanced stability and durability when drilling in medium to hard, more abrasive formations. Their four-wing design, compared to three-wing counterparts, offers greater contact with the borehole, promoting straighter holes and reducing deviation. This makes them particularly effective in areas containing significant rock content or where concrete and plugs may be encountered.

The robust construction and precise manufacturing details of these bits ensure prolonged service life and consistent performance in demanding conditions.

A solid one-piece heat-treated 4140 alloy steel body for bit strength & durability; The bit’s foundation is a single, robust piece of 4140 alloy steel, uniformly heat-treated to achieve superior structural integrity and exceptional resistance to wear and tear, ensuring longevity even in harsh drilling environments.
CNC threaded machining for proper installation & use: Utilizing advanced CNC machinery, the bit’s threads are precisely cut, guaranteeing a perfect, secure fit with the drill string. This precision minimizes wobbling and ensures stable, efficient power transfer during drilling operations.
Forgings are milled to seat the carbide inserts better. The bit’s forged components undergo a meticulous milling process. This creates perfectly shaped pockets that tightly cradle each carbide insert, ensuring optimal alignment and secure retention, which enhances cutting efficiency and bit lifespan.
Select tungsten carbide inserts 5.5 mm thick are standard. High-grade tungsten carbide inserts, each with a consistent 5.5 mm thickness, are carefully chosen for their extreme hardness and wear resistance. These inserts are strategically placed to maximize cutting action and extend the bit’s operational life.
Relief is hand-ground behind carbide inserts for maximum performance. Skilled craftsmen hand-grind specific relief angles behind each carbide insert. This crucial detail facilitates efficient cuttings evacuation, preventing material buildup and allowing the inserts to consistently engage the formation for peak drilling performance.
